Auto Single Unrolling Horizontal Coil Hydraulic Decoiler Machine With Pressing Arm

Name: Auto Single Unrolling Horizontal Coil Hydraulic Decoiler Machine With Pressing Arm
Brand: ZHONGHENG
Price: 5000 USD

Quality Auto Single Unrolling Horizontal Coil Hydraulic Decoiler Machine With Pressing Arm wholesale

Brand Name : ZHONGHENG

Model Number : ZHMST-5T

Certification : CE/SGS/ISO9001

Place of Origin : China

MOQ : 1 set

Price : $5000-15000/set

Supply Ability : 60 sets/months

Delivery Time : 30 working days

Packaging Details : packaged by waterproof plastic film cover

Voltage : 380V 50HZ 3Phazes

Coilcar : Available

Material : PPGI/GI/PPGL

Speed : 10-15m /min

Aftersale service : Engineer available

Motor : 5.5kw

Contact Now

Auto Single Unrolling Horizontal Coil Hydraulic Decoiler Machine With Pressing Arm

Description:

The uncoiler consists of the moving dolly, uncoiler with pressing arm,frame with lead rail, and hydraulic system.The moving dolly can be lifted,move on the lead rail , carry the coil to the uncoiler,the leafs of the uncoiler expanse , the coil be fixed on the uncoiler,main axis of the uncoiler rotate , the coil sheet comes out. After the coil sheet feed into the roll forming machine, the coil sheet will be pulled back to minimize the pendant.

Coil specifications

Model	MT-200	MT-300	MT-400	MT-500	MT-600	MT-700	MT-800	MT-1000	MT-1300	MT-1600
Material Width	200	300	400	500	600	700	800	1000	1300	1600
Material Thickness	2	2	2	2	2		2	2	2	2
Material I. D	450-530	450-530	450-530	450-530	450-530	450-530	450-530	450-530	450-600	450-600
Material O. D	1200
Material Weight (kg)	500	800	1000	2000	2000	3000	3000	3000	3000	3000
Speed of feed(m/min)	15	15	15	15	15		15	15	15	15
Coil Expansion	MANUAL
Motor(HP)	½	1	2	2	3		3	5	5	7.5

Specifications

Single unrolling machine	one side can put material
Adopt automatic hydraulic system for expand
Coil weight (Max)	5000kg
Inter diameter	460mm-560mm
Maximal out diameter	1250mm
Oil cylinder dia	120mm
Coil width (Max.)	1250mm
Working speed	0-15m/min adjustable
Main motor power	5.5KW AC motor
Hydraulic power	4kw
Frequency converter brand	Yaskawa
De-coiler should be with Loop control and hold down, and with baffle for forbid coil fall down
Machine have function of forward and reverse working
The decoiler has 3 segments
Color	blue or base on customer request
Quantity	1

Details of coilcar

Coil weight (Max)	5000kg
Inter diameter of coil	480mm-560mm
Working by hydraulic pressure	8-12Mpa with connect with the decoiler hydraulic unit
Working lift journey	Maximal 250mm
Working function	forward and reverse movable
Move journey	maximal 3 meters
Color	blue or base on customer request
Quantity	1

Competitive Advantage:

Low Noisy
Fully automatic
Save Labours
Big production
High speed
